MH-105A Automatic horizontal binding machine
Model:MH-105A
Power Supply:380V 50/60Hz 3.1kW
Compressed air pressure:0.4 ~0.6MPa
Binding speed:≤ 15s / Channel
Binding force:0-90kg
Strapping belt specification:9-15 (± 1) mm wide and 0.55-1.0 (± 0.1) mm thick
Belt disc specification:Width 160-180mm, inner diameter 200-210mm, outer diameter 400-500mm
Frame size:W1500mm × H1500mm (customized as required)
Overall size:L1930mm × W3240mm × H2800mm
Power Supply:380V 50/60Hz 3.1kW
Compressed air pressure:0.4 ~0.6MPa
Binding speed:≤ 15s / Channel
Binding force:0-90kg
Strapping belt specification:9-15 (± 1) mm wide and 0.55-1.0 (± 0.1) mm thick
Belt disc specification:Width 160-180mm, inner diameter 200-210mm, outer diameter 400-500mm
Frame size:W1500mm × H1500mm (customized as required)
Overall size:L1930mm × W3240mm × H2800mm
